Specifications Si34-704
28 Specifications
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name (Combination Unit) RXQ24PHY1 RXQ26PHY1
Model Name (Independent Unit) RXQ8PY1+RXQ8PY1+RXQ8PY1 RXQ8PY1+RXQ8PY1+RXQ10PY1
★
1 Cooling Capacity (19.5°CWB)
kcal / h 58,100 63,000
Btu / h 231,000 250,000
kW 67.6 73.2
★
2 Cooling Capacity (19.0°CWB) kW 67.2 72.8
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm (1680×930×765)+(1680×930×765)+(1680×930×765) (1680×930×765)+(1680×930×765)+(1680×930×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (13.72)+(13.72)+(13.72) (13.72)+(13.72)+(13.72+10.53)
Number of Revolutions r.p.m (7980)+(7980)+(7980) (7980)+(7980)+(6300,2900)
Motor Output×Number
of Units
kW (3.8×1)+(3.8×1)+(3.8×1) (3.8×1)+(3.8×1)+((1.2+4.5)×1)
Starting Method Soft start Soft start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW (0.75×1)+(0.75×1)+(0.75×1) (0.75×1)+(0.75×1)+(0.75×1)
Air Flow Rate m³/min 180+180+180 180+180+185
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm
φ
15.9(Brazing Connection)
φ
19.1(Brazing Connection)
Gas Pipe mm
φ
34.9(Brazing Connection)
φ
34.9(Brazing Connection)
Product Mass (Machine Weight) kg 205+205+205 205+205+249
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
Capacity Control % 7~100 6~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 7.7+7.7+7.7 7.7+7.7+8.4
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
