Other Control Si34-704
112 Function
5.2.2 In the Case of 1-Outdoor-Unit System (RXQ8P to 18P)
[Set the system to operation prohibition mode by compressor]
• In order to set an INV compressor to operation
prohibition mode, set No. 42 of Setting mode 2 to
"EMERGENCY OPERATION".
(Procedure)
(1) Press and hold the MODE button (BS1) for a
period of 5 seconds or more.
(2) Press the SET button (BS2) 42 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) once.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
• In order to set STD1 and STD2 compressors to
operation prohibition mode, set No. 19 of Setting
mode 2 to "STD1, 2 OPERATION PROHIBITION".
(RXQ10P to 18P)
(Procedure)
(1) Press and hold the MODE button (BS1) for a
period of 5 seconds or more.
(2) Press the SET button (BS2) 19 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) once.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
• In order to set the STD 2 compressor to operation
prohibition mode, set No. 19 of Setting mode 2 to "STD2
OPERATION PROHIBITION". (RXQ14P, 16P, 1
8P
)
(Procedure)
(1) Press and hold the MODE button (BS1) for a period
of 5 seconds or more.
(2) Press the SET button (BS2) 19 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) twice.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
• For RXQ14P, 16P and 18P, if the INV compressor
is set to operation prohibition mode, only a single STD compressor will operate for the
convenience of oil equalization.
• For RXQ14P, 16P and 18P, only the STD1 compressor cannot be put into operation
prohibition mode for the convenience of oil equalization.
• For the system with a single outdoor unit (RXQ8P to 18P), automatic backup operation is not
functional.
5.2.3 In the Case of Multi-Outdoor-Unit System (RXQ20P to 54P)
[Automatic backup operation]
With multi-outdoor-unit system, if a certain outdoor unit system malfunctions (i.e., the system
stops and indoor unit remote controller displays the malfunction), by resetting the system with
the indoor unit remote controller, the applicable outdoor unit is inhibited from operating for 8
hours, thus making it possible to perform emergency operation automatically.
However, in the event any of the following malfunctions occurs, automatic backup operation
can be performed.
Malfunctions under which automatic backup operation can be performed:
• E3, E4, E5, E7
•F3
•H7, H9
• J2, J3, J5, J6, J7, J9, JA, JC
• L3, L4, L5, L8, L9, LC
•U2, UJ
LED display (
7
:ON
7
7
:OFF
9
:Blink)
H1P
----
H7P
(Factory set)
7
777777
777777
77
7
77
7
77
7
7
7
7777
7777
7
7
9
7
777
777
7
7
97
7
7
777777
777777
77
777
7777
7777
LED display (
7
:ON
7
7
:OFF
9
:Blink)
H1P
----
H7P
(Factory set)
7
777777
777777
7
7
77
77
7777
7
777777
777777
7
7777
7777
97
7
7
777777
777777
77
777
7777
7777
LED display (
7
:ON
7
7
:OFF
9
:Blink)
H1P
----
H7P
(Factory set)
7
777777
777777
7
7
77
77
7777
7
777777
777777
7
7777
7777
97
7
7
777777
777777
77
777
7777
7777
