List of Electrical and Functional Parts Si34-704
346 Appendix
3.2 Indoor Side
3.2.1 Indoor Unit
Parts Name
Symbol
Model
Remark
FXFQ25
MVE
FXFQ32
MVE
FXFQ40
MVE
FXFQ50
MVE
FXFQ63
MVE
FXFQ80
MVE
FXFQ100
MVE
FXFQ125
MVE
Remote
Controller
Wired Remote
Controller
BRC1C62
Option
Wireless Remote
Controller
BRC7E61W
Motors
Fan Motor M1F DC380V 30W 8P DC 380V 120W 8P
Drain Pump M1P
AC220-240V (50Hz) AC220V (60Hz)
PLD-12230DM
Thermal Fuse 145°C
Swing Motor M1S
MP35HCA[3P007482-1]
Stepping Motor DC16V
Thermistors
Thermistor (Suction Air)
R1T In PC board A4P or wired remote controller
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-5
φ
8 L1000
20k
Ω
(25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-5
φ
6 L1000
20k
Ω
(25°C)
Others
Float Switch S1L FS-0211B
Fuse F1U 250V 5A
φ
5.2
Thermal Fuse TFu
—
Transformer T1R
—
Parts Name
Symbol
Model
Remark
FXCQ
20MVE
FXCQ
25MVE
FXCQ
32MVE
FXCQ
40MVE
FXCQ
50MVE
FXCQ
63MVE
FXCQ
80MVE
FXCQ
125MVE
Remote
Controller
Wired Remote
Controller
BRC1C62
Option
Wireless Remote
Controller
BRC7C62
Motors
Fan Motor M1F
AC 220~240V 50Hz
1
φ
10W 1
φ
15W 1
φ
20W 1
φ
30W 1
φ
50W 1
φ
85W
Thermal Fuse 152°C
—
Thermal protector
135°C : OFF
87°C : ON
Drain Pump M1P
AC220-240V (50Hz) AC220V (60Hz)
PLD-12230DM
Thermal Fuse 145°C
Swing Motor M1S
MT8-L[3PA07509-1]
AC200~240V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-6
φ
4 L1250
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-6
φ
8 L1250
20k
Ω
(25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-5
φ
6 L1000
20k
Ω
(25°C)
Others
Float Switch S1L FS-0211B
Fuse F1U 250V 5A
φ
5.2
Transformer T1R TR22H21R8
