![Daikin FXDQ20PVET [235/394] Outdoor unit malfunction of outdoor unit fan motor](/img/pdf.png)
Daikin FXDQ20PVET [235/394] Outdoor unit malfunction of outdoor unit fan motor
![Daikin FXDQ20PVET [235/394] Outdoor unit malfunction of outdoor unit fan motor](/views2/1702715/page235/bgeb.png)
Troubleshooting by Indication on the Remote Controller Si34-704
224 Troubleshooting
3.19
“
E7
”
Outdoor Unit: Malfunction of Outdoor Unit Fan Motor
Remote
Controller
Display
E7
Applicable
Models
RXQ5P~54P
Method of
Malfunction
Detection
Detect a malfunction based on the current value in the INVERTER PCB (as for motor 2, current
value in the fan PCB).
Detect a malfunction for the fan motor circuit based on the number of rotation detected by hole
IC during the fan motor operation.
Malfunction
Decision
Conditions
Overcurrent is detected for INVERTER PCB (A2P) or fan INVERTER PCB (A5P)
(System down is caused by 4 times of detection.)
In the condition of fan motor rotation, the number of rotation is below the fixed number for
more than 6 seconds. (System down is caused by 4 times of detection.)
Supposed
Causes
Failure of fan motor
Defect or connect ion error of the connectors/ harness between the fan motor and PCB
The fan can not rotate due to any foreign substances entangled.
Clear condition: Continue normal operation for 5 minutes
