Troubleshooting (OP: Unified ON/OFF Controller) Si34-704
310 Troubleshooting
[CHECK 8] Master Unit Central Connector Setting Table
The master unit central setting connector (CN1/X1A) is mounted at the factory.
• To independently use a single unit of the intelligent Touch controller or a single unit of the
central remote controller, do not dismount the master unit central setting connector (i.e., use
the connector with the factory setting unchanged).
• To independently use the schedule timer, insert an independent-use setting connector.
No independent-use setting connector has been mounted at the factory. Insert the
connector, which is attached to the casing of the main unit, in the PC board (CN1/X1A).
(Independent-use connector=Master unit central setting connector)
• To use two or more central equipment in combination, make settings according to the table
shown below.
(*1) The intelligent Touch controller and the schedule timer are not available for combined use.
(*2) The intelligent Touch controller, central remote controller, and the unified ON/OFF controller have been set to "Provided with the master
unit central setting connector" at the factory. The schedule timer has been set to "Not provided with the master unit central setting
connector" at the factory, which is attached to the casing of the main unit.
Pattern
Central equipment connection pattern Setting of master unit central setting connector(*2)
Intelligent
Touch
controller
Intelligent
Touch
controller
Central
remote
controller
Unified
ON/OFF
controller
Schedule
timer
Central
remote
controller
Unified
ON/OFF
controller
Schedule
timer
1 to 2
units
× (*1)
Only a
single unit:
"Provided",
Others: "Not
provided"
Only a
single unit:
"Provided",
Others: "Not
provided"
Only a
single unit:
"Provided",
Others: "Not
provided"
Only a
single unit:
"Provided",
Others: "Not
provided"
1 unit
1 unit
× (*1)
Provided Not provided
1 to 2
units
1 to 8
units
× (*1)
All "Not
provided"
All "Not
provided"
× (*1)
1 to 4
units
1 to 16
units
1 unit Not provided
1 unit Not provided
1 to 16
units
1 unit Not provided
1 unit Provided
