Si34-704 Troubleshooting by Indication on the Remote Controller
Troubleshooting 215
3.13
“
CJ
”
Indoor Unit: Malfunction of Thermostat Sensor in
Remote Controller
Remote
Controller
Display
CJ
Applicable
Models
AII indoor unit models
Method of
Malfunction
Detection
Malfunction detection is carried out by temperature detected by remote controller air
temperature thermistor. (Note:)
Malfunction
Decision
Conditions
When the remote controller air temperature thermistor becomes disconnected or shorted while
the unit is running.
Supposed
Causes
Defect of remote controller thermistor
Defect of remote controller PC board
Troubleshooting
Note:
∗
1: How to delete “the record of malfunction codes”.
Press the “Operate/ Stop” button for 4 seconds and more while the malfunction code is
displayed in the inspection mode.
∗
Refer to “Thermistor Resistance / Temperature Characteristics” table on P361.
Clear the malfunction code
history. (While in inspection
mode,
press and hold the
“ON/OFF”
button for a period of
five seconds or more.)
Is "CJ"
displayed on the remote
controller?
YES
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Replace remote controller.
External factor other than
equipment malfunction.
(for example, noise etc.)
(V2787)
NO
