Outline of Control (Indoor Unit) Si34-704
126 Function
(3) Thermostat OFF by discharge air temperature
<Cooling>
6.9.3 Low Outdoor Air Temperature Protection Control
Objective In cooling (or fan operation) or heating, if outdoor air is low in temperature, stop the fan forcibly.
Details [Cooling and fan operation]
Turn OFF the fan for a period of 60 minutes at a suction temperature of 5
°
C or lower.
In order to monitor the outdoor air temperature, however, turn ON the fan for a period of one
minute and turn OFF the fan again at a temperature of 5
°
C or lower after the said timer
completes the operative period.
Reset the 60-minute timer when the fan stops running.
Target discharge air temp. Ts – Discharge air temp. T4
>5 degree continue for 5 minutes.
→
Thermostat stops for 1 minute.
→
Thermostat ON
