Refrigerant Circuit Si34-704
60 Refrigerant Circuit
1. Refrigerant Circuit
1.1 RXQ5P
No. in
refrigerant
system
diagram
Symbol Name Major Function
A M1C Inverter compressor (INV)
Inverter compressor is operated on frequencies between 52Hz and 188Hz by using
the inverter. The number of operating steps is as follows when Inverter compressor is
operated.
RXQ5P : 18 steps
D M1F Inverter fan
Since the system is of air heat exchanging type, the fan is operated at 9-step rotation
speed by using the inverter.
EY1E
Electronic expansion valve
(Main: EV1)
Fully open.
G Y1S Solenoid valve (Hot gas: SVP) Used to prevent the low pressure from transient falling.
JY2S
Solenoid valve (Oil return: SVO)
Used to return oil from the accumulator to the compressor.
K Y4S Solenoid valve (Injection) SVT
Used to cool the compressor by injecting refrigerant when the compressor discharge
temperature is high.
M Y3S 4-way valve Fixed to cooling operation.
N S1NPH High pressure sensor Used to detect high pressure.
O S1NPL Low pressure sensor Used to detect low pressure.
PS1PH
HP pressure switch (For INV
compressor)
In order to prevent the increase of high pressure when a malfunction occurs, this
switch is activated at high pressure of 4.0 MPa or more to stop the compressor
operation.
T — Pressure regulating valve 1
This valve opens at a pressure of 4.0 MPa for prevention of pressure increase, thus
resulting in no damage of functional parts due to the increase of pressure in
transportation or storage.
W — Capillary tube
Used to return the refrigerating oil separated through the oil separator to the
compressor.
1 R1T Thermistor (Outdoor air: Ta) Used to detect outdoor temperature, correct discharge pipe temperature, and others.
2 R2T Thermistor (Suction pipe: Ts) Used to detect suction pipe temperature.
3R3T
Thermistor (INV discharge
pipe: Tdi)
Used to detect discharge pipe temperature, make the temperature protection control of
compressor, and others.
4R4T
Thermistor (Heat exchanger
deicer: Tb)
Used to detect liquid pipe temperature of air heat exchanger.
5 R6T Thermistor (Liquid pipe Tl) Used to detect liquid pipe temperature.
6R7T
Thermistor (Accumulator inlet
Ts1)
Used to detect gas pipe temperature at the accumulator inlet.
