Si34-704 Combination of Outdoor Units
General Information 7
High COP Series (Energy Saving Series)
Note: For multiple connection of 16HP system or more, an optional Daikin Outdoor Unit Multi
Connection Piping Kit is required.
System
Capacity
Number
of units
Module
Outdoor Unit Multi Connection Piping Kit
(Option)
8 1012141618
16HP 2 ●●
BHFP22P100
18HP 2 ●●
24HP 3 ●●●
BHFP22P151
26HP 3 ●● ●
28HP 3 ●● ●
30HP 3 ●●●
32HP 3 ●●●
34HP 3 ●●●
36HP 3 ●●●
38HP 3 ●● ●
40HP 3 ●● ●
42HP 3 ●● ●
44HP 3 ●●●
46HP 3 ●●●
48HP 3 ●●●
50HP 3 ●● ●
