Warning—Potential Damage: Do not touch the photoconductor drum. Doing so may aect the quality of
future print jobs.
5 Insert the new imaging unit.
Note: Use the arrows inside the printer as guides.
6 Insert the toner cartridge.
Note: Use the arrows inside the printer as guides.
Maintaining the printer 143
