VIP-2100 User’s manual - 96 -

root

irene

[root#] useradmin -add irene

Password : irene

Confirm : irene

Add user Success.

Add the new user account: irene

[root#] useradmin -delete

1111

Are You Sure?(Y/N)y

Delete the user: 1111

[root#] useradmin -password

root

New Password : 1234

Confirm : 1234

Change the user: root’s password.
