VIP-2100 User’s manual - 129 -
180 SDP: p Yes p No
183 SDP: p Yes p No
Local Codec Codec:
p G.711 a-law
p G.711 u-law
p G.729
p None
p G.723.1 (5.3K)
p G.723.1 (6.3A)
Accept Proxy Call Only: p Yes p No
PSTN Interface:
PCM encoding: p A-law p Mu-law
PCM Idle Pattern:
Default (-1): p 0x55 A-law p 0xff u-law p specified: ______
Clock Source: p External p Internal
p E1
Framing Method:
p Automatic CRC4 or Double Frame selection
p Double Frame Format
p CRC4 multi-frame
p CRC4 extend multi-frame
Line Code: p HDB3 p AMI
ISDN/PRI:
Termination Site: p Network p User site
Variance:
p Euro ISDN
p Australia ISDN
p Hong Kong ISDN
p Korea ISDN
CAS:
CAS Idle ABCD signal: Default (-1): specified: ______
p E1 MFC R2
p E1 CAS R2
Variance:
p E1 R2 MF Aregntina ANI
p E1 R2 MF Aregntina ANI 7digits
p E1 R2 MF Aregntina no ANI
p E1 R2 MF Aregntina no ANI 7 digits
p E1 R2 MF Bolivia ANI
p E1 R2 MF Bolivia ANI 7digits
p E1 R2 MF Bolivia no ANI
p E1 R2 MF Bolivia no ANI 7 digits
p E1 R2 MF Brazil ANI
p E1 R2 MF Brazil ANI 7digits
p E1 R2 MF Brazil no ANI
p E1 R2 MF Brazil no ANI 7 digits
p E1 R2 MF Chile ANI
p E1 R2 MF Chile ANI 7digits
p E1 R2 MF Chile no ANI
p E1 R2 MF Chile no ANI 7 digits
p E1 R2 MF China ANI
