VIP-2100 User’s manual - 86 -

Figure 7.5-1

Field Description:

• File Name: Upload the software file name

• Upload: Remote Upload the software at VIP-2100

• Apply: Remote apply the upload at VIP-2100

Relogin

Please refer section “Relogin”
