Planet VIP-2100 [114/140] Two stage dialing with aaa ip side aaa

VIP-2100 User’s manual - 109 -

Two Stage Dialing with AAA (IP Side AAA)

Example Description:

Components Contents

Start

Component ID:

1000

Next Component: 1001

CTB

Component ID:

1001

PSTN To: 1012

H.323 To: 1013

SIP To: 1019

1012 Route for PSTN call

MakeCall

Component ID:

1012

Route Mode: SIP Proxy

Finish To: 1013

Failed Other To: 1013

Disc

Component ID:

1013

Next Component: 1014
