VIP-2100 User’s manual - 49 -
Chapter 6 SIP to H.323 Mode Configuration
Environment used in this chapter
Process:
SIP → H.323 Call: DNIS (8861001) → DM (SIP In Drop) →Make H.323
(1001)
H.323 → SIP (8868888) → DM (H.323_in_drop) → Make Call (8888)
☺Digit Manipulation: Please refer section “Digit Manipulation”
Network Configuration
Please refer to section “Network Configuration”
Account Manager
Please refer to section “Account Manager”
Interface Configuration
Please refer to section “Interface Configuration”
H.323 Configuration
Please refer to section “H323 Configuration”
SIP Configuration
Please refer to section “SIP Configuration”
H323 VoIP
Network
SIP to H.323
H.323
Gateway
SIP VoIP
Net
work
H323
Phone
SIP USB
Phone
8888
SIP
Phone
