Planet VIP-2100 [107/140] One stage dialing sip proxy mode

VIP-2100 User’s manual - 102 -

One Stage Dialing (SIP Proxy Mode)

Example Description:

Components Contents

Start

Component ID:

1000

Next Component: 1001

CTB

Component ID:

1001

PSTN To: 1004

H.323 To: 1005

SIP To: 1007

1007 Route for SIP Proxy call

MakeCall

Component ID:

1007

Route Mode: PSTN

Finish To: 1005

Failed Other To: 1005

Disc

Component ID:

1005

Reason: PSTN normal call clear

Next Component: 1006

Quit

Component ID:

1006
