Planet VIP-2100 [90/140] Call flow editor

VIP-2100 User’s manual - 85 -

Figure 8.4-14

Delete Remote file:

Step 16: Click Delete Remote file button to delete remote voice file as figure

8.4-15.

Figure 8.4-15

Call Flow Editor

Please refer section “Call Flow Editor”

Account Manager

Please refer section “Account Manager”

Upgrade

Step 1: Click “Control→Upgrade” to upgrade the software as figure 7.5-1.
