VIP-2100 User’s manual - 84 -

Save Remote As: Refer the Section “Save Remote File”

Undo:

Step 13: Click Undo button to return modification, you can see the

configuration that haven’t be changed as figure 8.4-12.

Figure 8.4-12

Redo: Refer Section “Undo”

Zoom Zoom In Zoom Out:

Step 14: Select the desired voice range click Zoom button as figure 8.4-13.

Figure 8.4-13

Step 15: The screen shows the zoom out voice file range as figure 8.4-14.
