VIP-2100 User’s manual - 78 -

Network

DNS Server Setting:

Step 1: After successfully logon to the system, we need to change the

network configuration. Click Control→Network to setup the network

parameters as figure 8.3-1.

Figure 8.3-1

Parameter:

• Primary DNS Server: Primary DNS Server IP network

• Secondary DNS Server: Secondary DNS Server IP network

• Host Name: Host name used to register to DNS Server

• Domain Name: Domain name used to

• Dynamic DNS Registration: Enable Dynamic DNS registration or not

SNMP

Start path: Click Control→SNMP→Community

Figure 8.4-1

Parameter:
