VIP-2100 User’s manual - 9 -
6
VoIP Prepaid Support
Yes
Embedded AAA
1
Embedded Prepaid Service
Yes
2
Embedded Postpaid Service
Yes
3
Point/second Calculation
Yes
4
Second/point calculation
Yes
5
Auto Disable/Clean User
Yes
6
PSTN Prepaid Support
Yes
7
VoIP Prepaid Support
Yes
System Limitation
1
Max DM
4096
2
Max IP ACL
2048
3
Max DNIS ACL
4096
4
Max ANI ACL
4096
5
Max User ACL
20000
6
Max Phone Book Entries
10000
7
Max Call Flow Component
256
8
Max CDR Keep Days
5
9
Max Voice File Storage
10 hours
Manual
1
English User Guide
Yes
Содержание
- Port h 23 sip e1 t1 trunk gateway 1
- Contents 2
- Chapter 1 vip 2100 introduction 6
- System description 6
- Audio feature 7
- Technical specification 7
- Vip 2100 detail specifications 9
- Vip 2100 appearance description 15
- Chapter 2 logon vip 2100 16
- Logon vip 2100 16
- Network configuration 17
- System time configuration 18
- Account manager 19
- Relogin 21
- Chapter 3 h 23 gatekeeper and sip proxy mode configuration 22
- Environment used in this chapter 22
- Interface configuration 23
- T1 e1 trunk configuration 24
- H 23 configuration 26
- Sip configuration 27
- Digit manipulation 28
- Chapter 4 call flow editor 32
- Configuration management provides a way to save and reload the system configuration for future use 44
- Configuration manager 44
- Gatekeeper 44
- Sip proxy 44
- Vip 2100 user s manual 39 44
- Apply change 47
- Account manager 48
- Chapter 5 peer to peer mode configuration 48
- Environment used in this chapter 48
- Interface configuration 48
- Network configuration 48
- H 23 configuration 49
- Sip configuration 49
- Address book 50
- Call flow editor 51
- Digit manipulation 51
- Call flow p2p mode 52
- Configuration manager 52
- Peer to peer 52
- Please refer to section configuration manger 52
- Vip 2100 user s manual 47 52
- Apply change 53
- Account manager 54
- Chapter 6 sip to h 23 mode configuration 54
- Environment used in this chapter 54
- H 23 configuration 54
- Interface configuration 54
- Network configuration 54
- Sip configuration 54
- Address book 55
- Call flow editor 55
- Configuration manager 55
- Digit manipulation 55
- Apply change 56
- Chapter 7 advance configuration reference 57
- Configuration 57
- System configuration 57
- Interface configuration 58
- Dial plan configuration 60
- T1 e1 trunk configuration 60
- H 23 configuration 64
- Rest configuration 64
- Sip configuration 67
- Access control 73
- Number replace 76
- Routing plan 76
- Radius setting 78
- Apply change 80
- Chapter 8 system control 81
- System 81
- System time 81
- System time timezone setting 81
- Network 83
- Prompt manager 84
- Account manager 90
- Call flow editor 90
- Upgrade 90
- Relogin 91
- Chapter 9 system monitor 92
- Line summary status 92
- Event log 93
- Line detail 93
- Figure 9 2 figure 9 2 event description event id event description description 94
- Time event created time source executable program category event type none welltech sys event id event log note you can click clear button to clear all event log see the detail event log double click the log or select the log and click detail to see the log detail 94
- Vip 2100 user s manual 89 94
- Debug info 95
- Chapter 10 telnet rs 232 configuration 96
- Logon vip 2100 by telnet 96
- Command purpose 99
- Root time 99
- Root time 2003 07 29 23 14 53 change system bios time 99
- Root time show current time 99
- Root timezone 99
- Time reset or show system time 99
- Timezone setup or show system timzone timezone setup or show system timzone 99
- Vip 2100 user s manual 94 99
- Command purpose 100
- Please refer timezone to country mapping list useradmin manager user account 100
- Root timezone 40 n use pre defined timezone 100
- Root timezone custom 08 00 01 00 05 00 01 03 09 00 05 03 100
- Root timezone show current timezone info 100
- Root useradmin 100
- Root useradmin list show the current user account list rdmin 100
- Root useradmin show the current login user account 100
- Use customized timezone 100
- Vip 2100 user s manual 95 100
- Chapter 11 lcd display configuration 102
- Appendix 1 call flow example 105
- One stage dialing gatekeeper mode 105
- One stage dialing sip proxy mode 107
- One stage dialing peer to peer mode 109
- Two stage dialing voip pstn mixed call 111
- Example used call flow 113
- Gatekeeper 113
- Sip proxy 113
- Vip 2100 user s manual 108 113
- Two stage dialing with aaa ip side aaa 114
- Component id 1014 117
- Example used call flow example used call flow 117
- Vip 2100 user s manual 112 117
- Appendix 2 java plug in installation 118
- Appendix 3 retrieve cdr information 119
- Appendix 4 interface led description 121
- Appendix 5 build in voice prompt index 122
- Appendix 6 timezone to country mapping list 123
- Time zone 123
- Vip 2100 user s manual 118 123
- Vip 2100 user s manual 119 124
- Appendix 7 ip bandwidth requirement 125
- Appendix 8 release complete cause code 126
- Appendix 9 radius format attributes 129
- Radius format v2 start accounting request attributes 129
- Vip 2100 user s manual 124 129
- Stop accounting request attributes 130
- Vip 2100 user s manual 125 130
- Authentication request attributes 131
- Authentication response attribute 131
- Authorization request attributes 132
- Authorization response attributes 132
- Appendix 10 quick start check list 133
- Host network 133
- Sip call 133
- Voip configuration 133
- _____ _____ _____ _____ 133
- _____ _____ _____ _____ h 23 call voip configuration 133
- _____ _____ _____ _____ interface network 133
- Pstn interface 134
- Vip 2100 user s manual 129 134
- ______ 134
- Vip 2100 user s manual 130 135
- ______ 136
- Vip 2100 faq 137
- Example for sip mode 139
- Q8 does vip 2100 can cooperate with the cisco voip products answer the short answer is yes the following configuration example can be used for normal and fax call example for h 23 mode 139
- Vip 2100 user s manual 134 139
