VIP-2100 User’s manual - 57 -

- T1 DMS100 ISDN

- T1 NTT ISDN: used to connect NTT INS-1500 ISDN standard (Japan

Only)

- T1 HKT ISDN

- T1 QSIG

- T1 EURO ISDN

- T1 DMS100 MERIDIAL ISDN

- T1 NI1 ISDN

o For E1:

- E1 EURO ISDN: used for most of European ISDN standard

- E1 MFCR2

- E1 CAS

- E1 RAW CAS

- E1 AUSTEL ISDN: Australia E1 ISDN Variance

- E1 HKT ISDN: Hong E1 ISDN Kong Variance

- E1 KOR ISDN: Korea E1 ISDN Variance

- QSIO

- E1 TNZ ISDN

• Line Code: T1: you can choose AMI, B8ZS; E1: you can choose AMI,

HDB3

• PSTN Trace: PSTN layer debug trace. It will generate a debug trace file

for tracing purpose. Only enables it under Welltech technical supports

instruction and disable it when complete the debug

• Inbound DM Group: Digit Manipulation group used for incoming calls

associated to this trunk

• Outbound DM Group: Digit Manipulation group used for outgoing calls

• Local Ring Back: Provide ring back tone for PSTN or not. It only works

when VoIP outgoing Fast Start is disabled.

• Channel Mask: Channel mask for incoming or outgoing calls (default:

0xffffffff)

Start from MSB each bit, indicate a time, slot a trunk (e.g. 0x0000ffff:

0~15 B channel mask, 17~31 B channel free)

• Clock Master: PSTN trunk clock source

Advance Trunk Configuration:

Start Path: Configuration→Interface →Trunk →Advance
