WSG-404 User Guide
10
1.5 Technical Specifications
1.5.1 Hardware Specifications
LAN 4 x RJ45 (10Base-T/100Base-TX, Auto-Negotiation, Auto MDI/MDI-X)
1 x 802.11g wireless AP interface
WAN 1 x RJ45 (10Base-T/100Base-TX, Auto-Negotiation)
Ports
Console 1 x RJ11
Wireless Data rate Up to 54Mbps with Auto fall back with 802.11b
Wireless Encryption WEP 64/128 bit
WPA with TKIP
Wireless Authentication IEEE 802.1x (EAP-MD5, EAP-TLS, CHAP, PEAP)
WPA-PSK
Wireless Antenna Type 2dBi (Max) Dual detachable diversity antenna with reverse SMA
Wireless Operating Range Open Space: 100~300m
Indoors: 35~100m
LED Indicators 1 x POWER LED
1 x WLAN Link/Activity LED
1 x WAN Link/Activity LED
4 x LAN Link/Activity LEDs
Environmental Operating
Temperature: 5 ~ 45 °C
Relative Humidity: 10 ~ 80 % (non-condensing)
Storage
Temperature: - 25 ~ 55 °C
Relative Humidity: 5 ~ 90 % (non-condensing)
Electrical External Power Adaptor
Power Input: 12V DC, 1.5A
Regulatory Compliance FCC part 15 Class B
CE Mark Class B
Dimension 230 x 150 x 45.5 mm (W x D x H)
Weight 1.4 Kg
