WSG-404 User Guide
16
2.3 Software Configuration
2.3.1 Quick Configuration
There are two ways to configure the system: using Configuration Wizard or change the setting by
demands manually. The Configuration Wizard has 7 steps providing a simple and easy way to guide
you through the setup of PLANET WSG-404. Follow the procedures and instructions given by the
Wizard to enter the required information step by step. After saving and restarting PLANET
WSG-404, it is ready to use. There will be 7 steps as listed below:
1. Change Admin’s Password
2. Choose System’s Time Zone
3. Set System Information
4. Select the Connection Type for WAN Port
5. Set Authentication Methods
6. Set Wireless – Access Point Connection
7. Save and Restart PLANET WSG-404
To access the web management interface, connect the PC and WSG-404 in advance via the Private
Port of WSG-404. Then, launch the web browser and enter the IP address of the gateway for that
port in the address field then pres Enter. Default IP address of the default gateway of the Private
Port is https://192.168.2.254 (Note: https is used for a secured connection).
The administrator login page will appear. Enter default username “admin” & default password
“admin” in the User Name and Password fields. Click Enter to login.
