1. Introduction
The PLANET Wireless Subscriber Gateway WSG-404 is a compact intelligent gateway integrated
with a four-port port-based switch. It provides Plug & Play Internet access, advanced security and
network management.
The WSG-404 is designed for service providers, system integrator or hotspot venue operator
without backend-RADIUS-Server to have integrated solution for rapid deployment, which can start
hotspot service quickly and easily and enhance service performance.
The WSG-404 is an ideal solution for hotel lobbies, coffee bars, airport lounges, conference
facilities and other sites that commonly host business travelers, and offers instant high-speed
Internet connections. With its IP Plug and Play technology, it accepts any client configuration login,
when client open browser the WSG-404 immediately recognizes new end-user and redirects their
browser to customized Web pages. There’s no need for end-user to change any of their default
network (Static IP), e-mail (SMTP Server behind firewall), or browser settings (HTTP Proxy) or load
any special software to access hotspot service. It’s completely Plug’ Play with any browser.
1.1 Package Contents
Please inspect your package. The following items should be included in the WSG-404 packages:
1x WSG-404 unit
1x Power Adapter
1x User’s Manual CD
1x Quick Installation Guide
1x RJ-45 Cable
1x RS-232
2x Antenna
If any of the above items are damaged or missing, please contact your dealer immediately.
Optional Product that can co-work with WSG-404:
WSG-ACG4 Account Generator Printer
1x Power Adapter
1x RJ-11 Cable
1x Quick Installation Guide
This Account Generator is an optional device that can work with WSG-404. With this Account
Generator it is much easier for operator to create the accounts for any guests. Without the Account
Generator, all the account generation can be done through Administrator’s Web management page.
The demand of this Account Generator can vary on the install site
