Wireless Subscriber Gateway
11
1.5.2 Software Specifications
Network
IEEE802.3 10BaseT Ethernet
IEEE802.3u 100BaseTX Fast Ethernet
IEEE802.11b 11Mbps
IEEE802.11g 54Mbps
Supports 50 Simultaneous Users
IP Plug and Play (IP PnP)
Supports External HTTP Proxy Servers; Built-in Proxy Server
WEP Data Encryption 64/128 bit
WPA with TKIP; Radius
SMTP Server Redirection
DHCP Server
DHCP Relay
NAT
IP Routing
Dynamic DNS
Walled Garden: Up to 20
Session Number: Max. 16384
Supports NTP (Network Time Protocol)
WAN Connection Type
DHCP WAN Client
PPPoE WAN Client
PPTP WAN Client
Static IP WAN Client
AAA / Billing
Built-in Authentication
Exclusive Printer Accounting without PC operating
Web-based Login Page Authentication
Web-based Accounting
Flexible Billing Profiles and Price Plan
Flexible Billing Mechanism
Flexible Time Mechanism (Time to Finish and Accumulation)
External DB25 Support (WSG-ACG4)
RADIUS Authentication
Credit Card Support (Authorize.net, *PayPal)
10 Customizable Billing Profile
Remaining Credit Reminder
Accumulation Billing
Account log
*Future feature
Security
Layer 2 Isolation
SSL Login Page
SSL Administration
VPN Pass through (IPSec/PPTP)
Pass through Destination IP/URL
Pass through Source IP/MAC
Restricted Destination Filtering IP/URL
Share LAN Resources
Customize SSL Certificate
DoS Attack Protection
IEEE 802.1x (EAP-MD5, EAP-TLS, CHAP, PEAP)
Management
Supports Multiple Authentication Methods (Local and On-
demand, LDAP,
POP3(s), RADIUS, NT Domain)
