WSG-404 User Guide
116
3.5.2 Interface Status
This section provides an overview of the interface for the administrator including WAN, LAN1 &
LAN2, LAN3 & LAN4, and Wireless Port.
The description of the table is as follows.
Item Description
MAC Address The MAC address of the WAN port.
IP Address The IP address of the WAN port.
WAN
Subnet Mask The Subnet Mask of the WAN port.
Operation Mode The mode of the wireless port.
MAC Address The MAC address of the wireless port.
IP Address The IP address of the wireless port.
Subnet Mask The Subnet Mask of the wireless port.
SSID The ESSID of the wireless port.
Wireless
Channel The assigned Channel of the Wireless port.
