WSG-404 User Guide
6
1.2 Features
Ideal Hot Spot solution
Via the integrated 802.11g wireless interface, mobile users can establish high speed Internet
access without any configuration.
Zero configuration (Plug-n-Play) Internet access
WSG-404 translates proper IP address information for Internet access, all IP configurations,
either DHCP, Private IP or Static IP information will be turned into Internet-ready
configurations. Subscribers won’t feel the difference, and no need to face to the
inconvenience of IP reconfigurations.
Built-in proprietary AAA mechanism and billing system
PLANET WSG-404 integrates Web-based Authentication (including subscriber SSL logon
page), selective Web-based Accounting, and proprietary billing mechanism, which can help
you to prepare a billing mechanism in a very short time and bring most convenience, the least
efforts for billing applications.
RADIUS AAA support
WSG-404 provides standard based Radius Client to communicate with any standard based
Radius server, in order to support AAA (Authentication, Authorization and Accounting).
Exclusive Printer Accounting (Optional)
Machine operators may customize the printout information for different billing application.
Security and Firewall
With built-in 64/128-bit RC4 WEP Encryption, VLAN Security for Wireless, subscriber SSL
Login Page / Admin Page, VPN (IPSec/PPTP) Pass through…various security features,
PLANET WSG-404 bring you an ease-of-use and most comfort safe Internet access
environment.
Ease-of-Use and Management
The built-in web management interface in WSG-404 brings most convenience to system
administrators or machine operators while configuring machine or setting up subscriber
privileges in movements. With time increments, clerks or machine operators may print out,
billing and other user information with time increments are conveniently printed on the
button-operated printer included with the PLANET WSG-404. Time increments may be
compiled simply by pressing the printer button multiple times. No computers or complex
back-end subscriber management systems are required for deployment.
Virtual Server & DMZ Capability
The standard and user-defined Virtual server gives the WSG-404 has the most flexibility to
share local resources like Email, FTP or HTTP servers to the Internet in a more secure way.
The DMZ (De-Militarized Zone) capability helps LAN users to act like an independent Internet
node that communicates to the Internet in both directions while maintaining security for LAN
users.
Note:
The "PnP" Function only can be used with TCP/IP-based Network.
