Wireless Subscriber Gateway
125
5. Appendix B --- Configuration on Authorize.Net
Before the “Credit Card” and related functions can be managed appropriately, PLANET WSG-404
requires the merchant owners to have a valid Authorize.Net (www.authorize.net) account, since
Authorize.Net is the on-line payment gateway that PLANET WSG-404 supports now. The figure
below shows the process of the credit card billing and we will introduce some important procedures
for configurations on Authorize.Net.
Note:
A payment gateway “Paypal” will be supported in the future.
1. Setting Up
1.1 Open Accounts
As shown in the above figure, four elements are needed to begin an on-line business:
Element Description
E-COMMERCE WEB SITE
PLANET WSG-404 has built-in web pages to present to
end users to use credit cards
INTERNET MERCHANT
ACCOUNT
A type of bank account that allows a business to accept
Internet credit card
PAYMENT GATEWAY
ACCOUNT
An Authorize.Net account is the type of account that is
supported by PLANET WSG-404
CONNECTION METHOD
PLANET WSG-404 will take care of the communication
with the Authorize.Net
