WSG-404 User Guide
100
3.3 Network Configuration
This section includes the following functions: Network Address Translation, Privilege List,
Monitor IP List, Walled Garden List, Proxy Server Properties and Dynamic DNS.
3.3.1 Network Address Translate
There are three parts, Static Assignment, Public Accessible Server and Port and Redirect,
need to be set.
