User’s Manual of IGS-801M

4.9.3 802.1X Authentication Port Configuration

When 802.1X is enabled, you need to configure the parameters for the authentication process that runs between the client

and the switch (i.e., authenticator), as well as the client identity lookup process that runs between the switch and

authentication server. These parameters are described in this section. The 802.1X Port Configuration screen in Figure

4-9-5 appears.

Figure 4-9-5 Per Port network access control configure table

Figure 4-9-6 802.1X Network access control mode selection

The Network Access Control port configuration table includes the following fields:

Object Description

Port

Selects the port to be configured. When the selection is changed, a screen

refresh will occur causing all fields to be updated for the newly selected port.

101
