User’s Manual of IGS-801M

2. Select on the configuration file then click “Upload”, the bottom of the browser shows the upload status.

3. After down, the main screen appears “Transfer Completed”.

4.2.7 Factory Reset

The Factory Reset button can reset the Gigabit Ethernet Switch back to the factory default mode. Be aware that the entire

configuration will be reset; expect the IP address of the Gigabit Ethernet Switch. Once the Factory Reset item be pressed,

the screen in Figure 4-2-11 appears.

Figure 4-2-11 Factory Reset screen

To reset the IP address 168.0.100”. Press the hardware reset button

anel about 5 seconds. After the device be rebooted. You can login the management

WEB interface within the same subnet of 192.168.0.xx.

to the default IP Address “192.

at the bottom p

RESET

4.2.8 System Reboot

The Reboot page enables the device to be rebooted from a remote location. Once the Reboot button be pressed, user

have to re-login the WEB interface about 20 seconds later, the screen in Figure 4-2-12 appears.

Figure 4-2-12 Reboot screen
