User’s Manual of IGS-801M
Ingress Filtering Enable Enabled - the frame is discarded if this port is not a member of the VLAN
with which this frame is associated. In a tagged frame, the VLAN is
identified by the VLAN ID in the tag. In an untagged frame, the VLAN is the
Port VLAN ID specified for the port that received this frame.
Disabled - all frames are forwarded in accordance with the 802.1Q VLAN
bridge specification. The factory default is disabled.
Acceptable Frame Types
Specifies the types of frames that may be received on this port. The
options are 'All' and 'Tagged only'.
• All- untagged frames or priority tagged frames received on this port are
accepted and assigned the value of the Port VLAN ID for this port.
• Tagged only - untagged frames or priority tagged frames received on
this port are discarded.
With either option, VLAN tagged frames are forwarded in accordance to
the 802.1Q VLAN specification.
PVID Allow assign PVID for selected port. The range for the PVID is 1-4094
The PVID will be inserted into all untagged frames entering the ingress
port. The PVID must as same as the VLAN ID that the port belong to VLAN
group, or the untagged traffic will be dropped.
59
