User’s Manual of IGS-801M
Appendix A—RJ-45 Pin Assignment
.1 Switch's RJ-45 Pin Assignments
1000Mbps, 1000Bas
A
e T
C MDI MDI-X
ONTACT
1 BI_DA+ BI_DB+
2 BI_DA- BI_DB-
3 BI_DB+ BI_DA+
4 BI_DC+ BI_DD+
5 BI_DC- BI_DD-
6 BI_DB- BI_DA-
7 BI_DD+ BI_DC+
8 BI_DD- BI_DC-
Implicit implementation of the crossover function within a twisted-pair cable, or at a wiring panel, while not expressly
forbidden, is beyond the scope of this standard.
A.2 10/100Mbps, 10/100Base-TX
When connecting your 10/100Mbps Ethernet Switch to another switch, a bridge or a hub, a straight or crossover cable is
necessary. Each port of the Switch supports auto-MDI/MDI-X detection. That means you can directly connect the Switch
to any Ethernet devices without making a crossover cable. The following table and diagram show the standard RJ-45
receptacle/ connector and their pin assignments:
RJ-45
C
ONNECTOR PIN ASSIGNMENT
C
ONTACT
MDI MDI-X
M
EDIA
D
EPENDANT
I
NTERFACE
M
EDIA
D
EPENDANT
I
NTERFACE
-C
ROSS
1 T
X
+
(
TRANSMIT
) R
X
+
(
RECEIVE
)
2 T
X
-
(
TRANSMIT
) R
X
-
(
RECEIVE
)
3 R
X
+
(
RECEIVE
) T
X
+
(
TRANSMIT
)
4,
5 N
OT USED
6 R
X
-
(
RECEIVE
) T
X
-
(
TRANSMIT
)
7,
8 N
OT USED
109
