13
Chapter 3: Dashboard TabEdgeOS
™
User Guide
Ubiquiti Networks, Inc.
• Enable Watchdog Enable the use of Ping Watchdog.
‑ IP Address To Ping Specify the IP address of the
target host to be monitored by Ping Watchdog.
‑ Ping Interval Specify the time interval (in seconds)
between the ICMP echo requests that are sent by Ping
Watchdog. The default value is 300 seconds.
‑ Startup Delay Specify the initial time delay (in
seconds) until the first ICMP echo requests are sent by
Ping Watchdog. The default value is 300 seconds.
The Startup Delay value should be at least 60 seconds
as the network interface and wireless connection
initialization takes a considerable amount of time if
the device is rebooted.
‑ Failure Count Specify the number of ICMP echo
response replies. If the specified number of ICMP echo
response packets is not received continuously, Ping
Watchdog will reboot the device. The default value
is3.
‑ Cut power for Specify the number of seconds this
port should pause PoE (if applicable).
WARNING: Cutting power during a firmware
upgrade can damage your device. Ensure that you
specify a safe Ping Interval.
Click Save to apply your changes, or click Cancel.
