35
Chapter 7: Users Tab EdgeOS
™
User Guide
Ubiquiti Networks, Inc.
Chapter 7: Users Tab
The Users tab displays account information about users.
You can also configure these user accounts. Any setting
marked with a blue asterisk * is required.
You have two sub-tabs:
Local Displays configurable user accounts.
Remote Displays statistics about the users who remotely
access the EdgeRouter.
Local
Configure user accounts with unique logins.
Add User To create a new user, click Add User.
The Create New Local User screen appears.
Complete the following:
• Username Enter a unique account name for the user.
• Full Name Enter the actual name of the user.
• Password Enter the password.
• Confirm Enter the password again.
• Role Select the appropriate permission level:
- Admin The user can make changes to the
EdgeRouter configuration.
- Operator The user can view the EdgeRouter
configuration but cannot make changes.
Click Save to apply your changes.
Search Allows you to search for specific text. Begin
typing; there is no need to press enter. The results are
filtered in real time as soon as you type two or more
characters.
A table displays the following information about each
user. Click a column heading to sort by that heading.
Username The account name of the user is displayed.
Name The actual name of the user is displayed.
Level The permission level of the user is displayed.
Active Sessions The number of times the user has
accessed the EdgeRouter is displayed.
Date Connected The date of the user’s most recent
access is displayed.
Uptime The duration of the user’s access is displayed.
Status The status of the user is displayed.
