44
Chapter 9: ToolboxEdgeOS
™
User Guide
Ubiquiti Networks, Inc.
Start Click this button to start the capture. (If a Packet
Limit is not specified, then this button becomes a Stop
button during the capture.)
Capture results are displayed with Time and Packet
descriptions.
Log Monitor
The Log Monitor is a log displaying live updates.
Click the pause button to stop the live updates. Click the
play button to resume the live updates.
The System log messages table displays the following
information about each log. Click a column heading to
sort by that heading.
Time The system time is displayed next to every log entry
that registers a system event.
Message A description of the system event is displayed.
