97
12
MENU SCREEN OPERATION
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
D Monitor key action
The monitor key, [SQL] , can be set as a ‘sticky’ key. When
set to the sticky condition, each push of [SQL] toggles the
monitor function ON and OFF.
• PUSH : Pushing and holding [SQL] to monitor the fre-
quency. (default)
• HOLD : Push [SQL] momentarily to monitor the frequency
and push momentarily again to cancel it.
D Dial speed acceleration
The dial speed acceleration automatically speeds up the
tuning dial speed when rotating [DIAL] rapidly.
• OFF : The dial speed acceleration is turned OFF.
• ON : The dial speed acceleration is tuned ON.
(default)
D Auto repeater
U.S.A. version only
The auto repeater function automatically turns ON or OFF
the duplex operation and tone encoder. The offset and re-
peater tone is not changed by the auto repeater function.
Reset these frequencies, if necessary.
• OFF : The auto repeater function is turned OFF.
• RPT1 : Activates for duplex only. (default)
• RPT2 : Activates for duplex and tone.
PUSH
PUSH
HOLD
HOLD
MONITOR
MONITOR
r
HOLD
HOLD
PUSH
PUSH
MONITOR
MONITOR
r
ON
ON
OFF
OFF
DIAL SPEED-UP
DIAL SPEED-UP
r
OFF
OFF
ON
ON
DIAL SPEED-UP
DIAL SPEED-UP
r
RPT1
RPT1
OFF
OFF
RPT2
RPT2
AUTO REPEATER
AUTO REPEATER
r
OFF
OFF
RPT1
RPT1
RPT2
RPT2
AUTO REPEATER
AUTO REPEATER
r
