Icom IC-92AD [50/156] D repeater operation in the same zone
![Icom IC-92AD [50/156] D repeater operation in the same zone](/views2/1074086/page50/bg32.png)
New
42
7
DV MODE OPERATION
New2001
D Repeater operation in the same zone
q Set the desired repeater’s frequency, offset and shift di-
rection in B band. (pgs. 18, 31)
• Select DV mode in advance. (p. 21)
w Set your own call sign. (p. 38)
• See p. 34 for your own call sign programming.
e Set the desired station call sign. (p. 39)
• See p. 36 for station call sign programming.
r Set the repeater’s call sign as follows;
z Enter “R1” in call sign set mode.
• Pushing and holding [CS](9) for 1 sec. is also available to
enter call sign set mode.
x Rotate [DIAL]
†
to select the nearest repeater’s call sign.
c Push [
](5) to set the call sign for “R1.”
• Return to CALL SIGN screen.
v Rotate [DIAL]
†
to select “R2” then push [ ](5)
†
.
• RPT2 CALL SIGN screen is displayed.
b Rotate [DIAL]
†
to select the desired repeater’s (in the
same zone) call sign.
• Select “NOT USE✱” when not operating RPT2.
n Push [ ](5) to set the call sign for “R2.”
• Return to CALL SIGN screen.
m Push [MENU/ ] to return to frequency indication.
t Push [PTT] to transmit; release to receive.
†
[DIAL] ↔ [ ](2)/[ ](8)
‡
[ ](5) ↔ [ ](6)
❮MENU screen❯ ➪ ❮CALL SIGN❯ ➪ ❮R1❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
UR:CQCQCQ
UR:CQCQCQ
R1:RPT1AA
R1:RPT1AA
R2:NOT USE*
R2:NOT USE*
MY:MYCALL
MY:MYCALL
/IC92
/IC92
CALL SIGN
CALL SIGN
r
