New
16
4
FREQUENCY AND CHANNEL SETTING
New2001
D Call/TV*/Weather
†
channels
Call channels are used for quick recall of most-often used
frequencies.
* Appears only when TV channels are programmed via the
optional RS-92. Also available for A band operation only.
†
Available for the U.S.A. version only.
q Push [CALL] several times to select call channels/TV
channels (A band only)/Weather channels.
• Call/TV/Weather channels can be selected in sequence.
w Rotate [DIAL] to select the desired channel.
■ Operating band selection
The transceiver can receive the AM broadcast, HF bands,
50 MHz, FM broadcast, VHF air, 144 MHz, 300 MHz, 400
MHz or 800 MHz* bands.
(Some bands are not selectable for B
band operation. See next page for details.)
➥ In VFO mode, push [BAND] several times to select the
desired frequency band.
• If VFO mode is not selected, such as a memory channel/call
channel/TV channel/Weather channel, push [VFO] to select
VFO mode fi rst, then push [BAND] to select the desired band.
➥ While pushing and holding [BAND], rotating [DIAL] also
selects the frequency band.
Available frequency bands are different depending on ver-
sion. See the specifi cation for details. (pgs. 135, 136)
* Some frequency ranges are blocked for the U.S.A. ver-
sion by regulation.
[DIAL]
CALL
RX
CS
C
A
MemoName
MemoName
µ
PRIO
PRIO
WX
WX
EMR
EMR
DTCS
DTCS
FM
FM
LOW
LOW
ATT
ATT
14
145
000
000
P
SKIP
SKIP
+DUP
+DUP
C0
C0
TV
TV
A
MemoName
MemoName
µ
PRIO
PRIO
WX
WX
EMR
EMR
DTCS
DTCS
WFM
WFM
LOW
LOW
ATT
ATT
10
ch
ch
P
SKIP
SKIP
+DUP
+DUP
25
25
WX
WX
A
MemoName
MemoName
µ
PRIO
PRIO
WX
WX
EMR
EMR
DTCS
DTCS
LOW
LOW
ATT
ATT
1
ch
ch
P
SKIP
SKIP
+DUP
+DUP
25
25
• Call channel indication
• TV channel indication
• Weather channel indication
BAND
D
[DIAL]
A
MemoNameMemoName
µ
PRIOPRIO WXWX EMREMR
DTCSDTCS
FMFM
LOWLOW
ATTATT
14145 000000
PSKIPPSKIP
+DUP+DUP
000000
