99
12
MENU SCREEN OPERATION
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
D PTT lock
Turns the PTT lock function ON and OFF.
Transmission with [PTT] is inhibited when ON is selected to
prevent accidental transmission, etc. (default: OFF)
D Busy lockout
Turns the busy lockout function ON and OFF.
This function inhibits transmission while receiving a signal or
when the squelch is open. (default: OFF)
D Time-out timer
To prevent accidental prolonged transmission, etc., the
transceiver has a time-out timer. This function cuts transmis-
sion OFF after 1, 3, 5 or 10 min. of continuous transmission.
This timer can be cancelled.
• OFF : The time-out timer is turned OFF. (default)
• 1 to 10 MIN : The transmission is cut OFF after the set
period elapses.
D Active band
Allows continuous frequency selection of the operating fre-
quency across all bands.
• SINGLE : A single operating frequency can be
selected within the current band. Push
[BAND] for band selection in this case.
• ALL : The operating frequency can be selected
continuously. (default)
D Dial replace
Exchanging [DIAL] and [VOL] function.
• OFF : The dial replace function is turned OFF.
(default)
• ON : The dial replace function is turned ON.
OFF
OFF
ON
ON
PTT LOCK
PTT LOCK
r
OFF
OFF
ON
ON
PTT LOCK
PTT LOCK
r
OFF
OFF
ON
ON
BUSY LOCKOUT
BUSY LOCKOUT
r
OFF
OFF
ON
ON
BUSY LOCKOUT
BUSY LOCKOUT
r
OFF
OFF
1MIN
1MIN
3MIN
3MIN
5MIN
5MIN
10MIN
10MIN
TIME-OUT TIMER
TIME-OUT TIMER
r
OFF
OFF
1MIN
1MIN
3MIN
3MIN
5MIN
5MIN
10MIN
10MIN
TIME-OUT TIMER
TIME-OUT TIMER
r
ALL
ALL
SINGLE
SINGLE
ACTIVE BAND
ACTIVE BAND
r
ALL
ALL
SINGLE
SINGLE
ACTIVE BAND
ACTIVE BAND
r
ON
ON
OFF
OFF
DIAL REPLACE
DIAL REPLACE
r
ON
ON
OFF
OFF
DIAL REPLACE
DIAL REPLACE
r
