REPEATER AND DUPLEX OPERATIONS
New2001
■ Auto repeater function
The U.S.A. version automatically use standard repeater set-
tings
(duplex ON/OFF, duplex direction, tone encoder ON/OFF)
when the operating frequency falls within or outside of the
general repeater output frequency range. The offset and
repeater tone frequencies are not changed by the auto re-
peater function. Reset these frequencies, if necessary.
D Frequency range and offset direction
• U.S.A. version
q Enter “AUTO RPT” in set mode. (p. 97)
w Rotate [DIAL]
†
to select the auto repeater setting.
• “RPT1” : Activates duplex only. (default)
• “RPT2” : Activates duplex and tone.
• “OFF” : Auto repeater function is turned OFF.
e Push [ ](5) (or [ ](4)) to return to set mode, and push
[MENU/
] to return to frequency indication.
FREQUENCY RANGE SHIFT DIRECTION
147.000–147.395 MHz “+DUP” appears
442.000–444.995 MHz “+DUP” appears
447.000–449.995 MHz “–DUP” appears
145.200–145.495 MHz
146.610–146.995 MHz
“–DUP” appears
❮MENU screen❯ ➪ ❮SET MODE❯ ➪ ❮AUTO RPT❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
U.S.A. version only
