MENU SCREEN OPERATION
New2001
D GPS auto TX timer
Selects the desired interval for automatic position transmis-
sion function from OFF (default), 5, 10, 30 second, 1, 3, 5,
10 and 30 minutes.
NOTE: When 4th GPS sentence are selected at “GPS
SENTENCE” (pgs. 102, 103), “5SEC” can not be se-
lected.
D DV auto detect
When a signal other than DV mode is received during DV
mode operation, the transceiver has capability of automatic
FM mode selection.
• OFF : Operating mode is fi xed in DV.
(default)
• ON : The transceiver automatically selects FM
mode for temporary operation.
D Call sign edit record
Selects call sign programming when the call sign is edited or
corrected with the pre-programmed call sign.
• OFF : The edited or corrected call sign is over writ-
ten.
• SELECT : The edited or corrected call sign is pro-
grammed into the selected call sign memory.
• AUTO : The edited or corrected call sign is pro-
grammed into a blank channel automatically.
(default)
†
