Icom IC-92AD [69/156] 2 3 4 5 6
![Icom IC-92AD [69/156] 2 3 4 5 6](/views2/1074086/page69/bg45.png)
61
8
GPS/GPS-A OPERATION
New2001
7
1
2
3
4
5
6
8
9
10
11
12
13
14
15
16
17
18
19
D GPS message programming
q Enter “GPS” in message/position set mode.
• GPS MESSAGE screen is displayed.
w Push [ ](6) to select the message edit condition.
• The 1st digit of the message blinks.
e Rotate [DIAL]
†
to select the desired character or symbol.
• Push [A/a](3) to change the character group from “AB” (alpha-
betical characters; capital letters), “ab” (alphabetical characters;
lower case letters), “12” (numbers) and “ !” ” (symbols) in se-
quence.
r Push [ ](6) to select 2nd digit, then rotate [DIAL]
†
to se-
lect the desired character or code.
• Push [ ](6) to move the cursor right; push [ ](4) to move the
cursor left.
• 2nd digit blinks (1st digit stops blinking).
t Repeat the steps r and t to enter the desired message.
• Up to 20-character messages can be set.
y Push [ ](5) to store the message.
u Push [MENU/
] to return to frequency indication.
❮MENU screen❯ ➪ ❮MESSAGE/POSITION❯ ➪ ❮GPS❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
DATA:
DATA:
AB
AB
†
:SET
:SET
:SEL
:SEL
:CUR
:CUR
CLR:CLR
CLR:CLR
GPS MESSAGE
GPS MESSAGE
A/a:CHAR
A/a:CHAR
r
DATA:
DATA:
AB
AB
Hello!
Hello!
†
:SET
:SET
:SEL
:SEL
:CUR
:CUR
CLR:CLR
CLR:CLR
GPS MESSAGE
GPS MESSAGE
A/a:CHAR
A/a:CHAR
r
†
[DIAL] ↔ [ ](2)/[ ](8)
‡
[ ](5) ↔ [ ](6)
NOTE: Set the GSV sentence to OFF when sending the
GPS message to conventional digital transceivers
(IC-2820, IC-D800H, IC-91AD, IC-V82, IC-U82).
The GSV sentence is incompatible with them.
Those transceivers will not display GPS messages
properly if sent as a GSV sentence from the IC-
92AD.
