DV MODE OPERATION
7
Although [DIAL] and [ ](5) are used for description in this
section, [
](2)/[ ](8) and [ ](6) are available instead of
[DIAL] and [
](5).
■ Digital mode operation
The IC-92AD can be operated in digital voice mode and
low-speed data operation for both transmit and receive. It
can also be connected to a GPS receiver
(compatible with an
RS-232 output/NMEA format/4800 bps/9600 bps) and transmit/re-
ceive position data.
■ Call sign programming
Four types of call sign memories are available; your own
call sign “MY CALL SIGN,” other station call sign “YOUR
CALL SIGN,” repeater call sign “RPT1 CALL SIGN” and
“RPT2 CALL SIGN.” “MY CALL SIGN” can store up to 6 call
signs, “YOUR CALL SIGN” can store up to 60 call signs and
“RPT1/2 CALL SIGN” can store up to 60 call signs, and each
call sign can be programmed with up to 8 characters.
D Your own call sign programming
Your own call sign must be programmed for both digital voice
and low-speed data communications (including GPS transmis-
sion).
q Select B band as the main band.
(p. 14)
w Enter “MY” in call sign set mode.
• Pushing and holding [CS](9) for 1 sec. is also available to enter
call sign set mode.
• MY CALL SIGN screen is displayed.
e Rotate [DIAL]
†
to select the desired call sign memory,
“M01” to “M06.”
r Push [
](6) to enter call sign programming mode.
• The 1st digit blinks.
t Rotate [DIAL]
†
to select the desired character or code.
• Push [A/a](3) to change the character group from “AB” (alpha-
betical characters; capital letters), “12” (numbers) and “/” (sym-
bols) in sequence.
M01
M01
/
/
:SET
:SET
:BACK
:BACK
:SEL
:SEL
:EDIT
:EDIT
CLR:CLR
CLR:CLR
MY CALL SIGN
MY CALL SIGN
r
M01
M01
†
/
/
MY CALL SIGN
MY CALL SIGN
r
:SET
:SET
:SEL
:SEL
:CUR
:CUR
CLR:CLR
CLR:CLR
A/a:CHAR
A/a:CHAR
AB
AB
❮MENU screen❯ ➪ ❮CALL SIGN❯ ➪ ❮MY❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
