Icom IC-92AD [66/156] Other functions for dv mode operation
![Icom IC-92AD [66/156] Other functions for dv mode operation](/views2/1074086/page66/bg42.png)
58
7
DV MODE OPERATION
New2001
D DV voice memory
The IC-92AD has a DV voice memory that records a total 30
second
(approx.) of received audio.
The DV voice memory is divided into 2 tracks, 15 seconds
each in a track, as the default setting.
◆ Recording received audio
q Select DV mode in B band, and deactivate the priority
watch
(p. 91) and weather alert function (p. 128) if activated.
w While receiving a DV signal, push [REC].
e Rotate [DIAL] to select the desired track.
• “✱” is displayed beside the track number when the selected
track has been recorded.
r Push [REC] to start recording.
• Track counter (bar meter) is displayed during record.
• The recording is paused automatically when the DV signal is
interrupted or when the DV audio signal cannot be received
correctly. Re-starts the recording when the DV audio signal is
received correctly.
t Push [REC] again to stop recording.
• The recording stops automatically when the track becomes full.
◆ Track size setting
The track size can be changed with the following instruction.
q Enter “TRACK SIZE” in DV voice memo set mode.
• TRACK SIZE screen is displayed
w Rotate [DIAL]
†
to select the desired track size.
10S/3TRACK : Makes 3 tracks and 10 seconds audio
can be recorded in each track.
15S/2TRACK : Makes 2 tracks and 15 seconds audio
can be recorded in each track.
30S/1TRACK : Makes 1 track only and 30 seconds audio
can be recorded in a track.
e Push [
](5) (or [ ](4)) to return to DV VOICE MEMO
screen.
r Push [MENU/
] to return to frequency indication.
New
■ Other functions for DV mode operation
DV
DV
B
44
440
012
012
50
50
q
REC TRACK:2
REC TRACK:2
❮MENU screen❯ ➪ ❮DV VOICE MEMO❯ ➪ ❮TRACK SIZE❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
10S/3TRACK
10S/3TRACK
15S/2TRACK
15S/2TRACK
30S/1TRACK
30S/1TRACK
TRACK SIZE
TRACK SIZE
r
