DSC OPERATION
6
D Transmitting a Position Reply Call
Transmit a Position Reply Call when a Position Request Call
is received.
q Enter “2QUKVKQP4GRN[” in the DSC menu.
❮&5%/GPW❯ ➪ ❮2QUKVKQP4GRN[❯
(Push [MENU]) (Rotate [SELECTOR], then push [ENT].)
w Rotate [SELECTOR] to select the desired individual ad-
dress or ID code, then push [ENT].
When a GPS receiver (NMEA0183 ver. 2.0 or 3.01) is
connected, next steps e and r (Current position/time
programming) do not appear. Go to step t.
e
The position information appears. Edit your position data
(latitude and longitude) by pushing the keypad keys. (p. 18)
r After editing the position data, then push [ENT] to set. Edit
the current UTC time by pushing the keypad keys, then
push [ENT].
&5%
&5%
/GPW
/GPW
2QUKVKQP
2QUKVKQP
4GRN[
4GRN[
4GCF[
4GCF[
%.4
%.4
'ZKV
'ZKV
'061-
'061-
t Push [ENT] to transmit the Position Reply Call to the se-
lected station.
• Your position data is transmitted, when [ENT] is pushed.
D Transmitting a Position Report Reply Call
Transmit a Position Report Reply Call when a Position Re-
port Call is received.
q Enter “2154GRQTV4GRN[” in the DSC menu.
❮&5%/GPW❯ ➪ ❮2154GRQTV4GRN[❯
(Push [MENU]) (Rotate [SELECTOR], then push [ENT].)
w Rotate [SELECTOR] to select the desired individual ad-
dress or ID code, then push [ENT].
e Push [ENT] to transmit the Position Report Reply Call to
the selected station.
D Transmitting a Polling Reply Call
Transmit a Polling Reply Call when a Polling Request Call is
received.
q Enter “2QNNKPI4GRN[” in the DSC menu.
❮&5%/GPW❯ ➪ ❮2QNNKPI4GRN[❯
(Push [MENU]) (Rotate [SELECTOR], then push [ENT].)
w Rotate [SELECTOR] to select the desired individual ad-
dress or ID code, then push [ENT].
e Push [ENT] to transmit the Polling Reply Call to the se-
lected station.
