Icom IC-M604A [47/68] Dsc set mode
![Icom IC-M604A [47/68] Dsc set mode](/views2/1074297/page47/bg2f.png)
41
6
DSC OPERATION
6
■ DSC Set mode
D Add Individual ID/Group ID (See pages 16, 17)
D Delete Individual ID/Group ID (See page 17)
D MMSI Code Check
The programmed 9 digit MMSI (DSC self ID) code can be
checked in the DSC Set mode.
q Enter “//5+%JGEM” in the DSC Set up menu.
❮&5%/GPW❯ ➪ ❮5GVWR❯ ➪ ❮//5+%JGEM❯
(Push [MENU]) (Rotate [SELECTOR], then push [ENT].)
w Check the 9 digit MMSI (DSC self ID) code.
&5%
&5%
/GPW
/GPW
//5+
//5+
%JGEM
%JGEM
%.4
%.4
'ZKV
'ZKV
e Push [CLR] to return to the DSC Set up menu.
r Push [CLR] or rotate [SELECTOR] to select “'ZKV,”
then push [ENT] to return to the DSC menu.
• Push [ENT] again to return to the normal operating mode.
D Automatic Acknowledgement
This item sets the automatic acknowledgement function to
ON or OFF.
When a position request, position report or polling request
call is received, the transceiver automatically transmits a po-
sition request reply, position report reply or polling reply call,
respectively.
q Enter “2QUKVKQP#WVQ#%-” in the DSC menu.
❮&5%/GPW❯ ➪ ❮5GVWR❯ ➪ ❮2QUKVKQP#WVQ#%-❯
(Push [MENU]) (Rotate [SELECTOR], then push [ENT].)
w Rotate [SELECTOR] to turn the automatic acknowledge-
ment function ON or OFF
.
&5%
&5%
/GPW
/GPW
2QUKVKQP
2QUKVKQP
#WVQ
#WVQ
#%-
#%-
10
10
1((
1((
%.4
%.4
'ZKV
'ZKV
'061-
'061-
e Push [ENT] to return to the DSC Set up menu.
r Push [CLR] or rotate [SELECTOR] to select “'ZKV,”
then push [ENT] to return to the DSC menu.
• Push [ENT] again to return to the normal operating mode.
