SiBE12-712C Troubleshooting
Service Diagnosis 207
4. Troubleshooting
4.1 Error Codes and Description
★
: Displayed only when system-down occurs.
Code Indication Description
Reference
Page
System
00
Normal —
U0★
Insufficient gas 238
U2
Over-voltage detection / low-voltage detection 240
U4
Outdoor unit PCB abnormality or signal transmission circuit abnormality 242
UA
Unspecified voltage (between indoor and outdoor units) 241
UH
Anti-icing function in other rooms 241
Indoor
Unit
A1
Indoor unit PCB abnormality 208
A5
Freeze-up protection control or high pressure control 209
A6
Fan motor or related
abnormality
AC motor (Wall : FTK(X)S-C, ATK(X)S-D series, Duct, Floor /
Ceiling)
211
DC motor (Wall : FTK(X)S-D, ATK(X)S-E series, F(C)TXG-E,
ATXG-E series, Floor)
212
C4
Heat exchanger temperature thermistor abnormality 214
C7
Front Panel Open / Close Fault 215
C9
Room temperature thermistor abnormality 214
Outdoor
Unit
A5
Anti-icing function 216
E5★
OL activation (compressor overload) 218
E6★
Compressor lock 219
E7
DC fan lock 220
E8
Input over current detection 221
F3
Discharge pipe temperature control 223
F6
High pressure control in cooling 224
H0
Compressor sensor system abnormality 226
H6
Position sensor abnormality 227
H8
DC voltage / DC current sensor abnormality 229
H9
Outdoor air thermistor or related abnormality 230
J3
Discharge pipe temperature thermistor or related abnormality 230
J6
Heat exchanger temperature thermistor or related abnormality 230
J8
Liquid pipe temperature thermistor or related abnormality 230
J9
Gas pipe temperature thermistor or related abnormality 230
L3
Electrical box temperature rise 232
L4
Radiation fin temperature rise 234
L5
Output over current detection 236
P4
Radiation fin thermistor or related abnormality 230
