Specifications SiBE12-712C
32 Specifications
50Hz 220-230-240V
Model
CTXG50EV1BW CTXG50EV1BS
Cooling Heating Cooling Heating
Rated Capacity 5.0kW Class 5.0kW Class
Front Panel Color Mat Crystal White Mat Crystal Silver
Airflow Rates
m³/min
(cfm)
H 11.3 (398) 12.6 (444) 11.3 (398) 12.6 (444)
M 9.1 (320) 10.6 (373) 9.1 (320) 10.6 (373)
L 7.1 (250) 8.7 (306) 7.1 (250) 8.7 (306)
SL 6.7 (236) 7.7 (271) 6.7 (236) 7.7 (271)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13 0.15-0.14-0.13
Power Consumption (Rated) W 30-30-30 30-30-30 30-30-30 30-30-30
Power Factor % 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2 90.9-93.2-96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 275×840×150 275×840×150
Packaged Dimensions (H×W×D) mm 222×894×345 222×894×345
Weight kg 9 9
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 47/41/35/32 47/41/35/32 47/41/35/32 47/41/35/32
Sound Power H dBA 64 64 64 64
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051105 3D051106
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
