List of Functions SiBE12-712C
12 List of Functions
Category Functions
2MXS40/50FV1B
Category Functions
2MXS40/50FV1B
Basic
Function
Inverter (with Inverter Power Control) { Health &
Clean
Air Purifying Filter —
Operation Limit for Cooling (°CDB)
10
~
46
Photocatalytic Deodorizing Filter —
Operation Limit for Heating (°CWB)
–10
~
24
Air Purifying Filter with Photocatalytic
Deodorizing Function
—
PAM Control
{
Titanium Apatite Photocatalytic
Air-Purifying Filter
—
Compressor Oval Scroll Compressor — Mold Proof Air Filter —
Swing Compressor
{
Wipe-clean Flat Panel —
Rotary Compressor — Washable Grille —
Reluctance DC Motor
{
Mold Proof Operation —
Comfortable
Airflow
Power-Airflow Flap — Heating Dry Operation —
Power-Airflow Dual Flaps — Good-Sleep Cooling Operation —
Power-Airflow Diffuser — Timer Weekly Timer —
Wide-Angle Louvers — 24-Hour On/Off Timer —
Vertical Auto-Swing (Up and Down) — Night Set Mode —
Horizontal Auto-Swing (Right and Left) — Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) —
3-D Airflow — Self-Diagnosis (Digital, LED) Display
{
★
2
Comfort Airflow Mode — Wiring-Error Check —
3-Step Airflow (H/P Only) —
Anticorrosion Treatment of Outdoor
Heat Exchanger
{
Comfort
Control
Auto Fan Speed —
Flexibility Multi-Split / Split Type Compatible
Indoor Unit
—
Indoor Unit Quiet Operation — Flexible Voltage Correspondence —
Night Quiet Mode (Automatic) — High Ceiling Application —
Outdoor Unit Quiet Operation (Manual)
{
Chargeless 20m
INTELLIGENT EYE — Either Side Drain (Right or Left) —
Quick Warming Function
{
Power-Selection
{
Hot-Start Function —
Remote
Control
5-Rooms Centralized Controller
(Option)
—
Automatic Defrosting
{
Remote Control Adaptor
(Normal Open-Pulse Contact) (Option)
—
Operation
Automatic Operation —
Remote Control Adaptor
(Normal Open Contact) (Option)
—
Programme Dry Function — DIII-NET Compatible (Adaptor) (Option) —
Fan Only — Remote
Controller
Wireless —
Lifestyle
Convenience
New POWERFUL Operation
(Non-Inverter)
—Wired —
Inverter POWERFUL Operation —
Priority-Room Setting —
Cooling / Heating Mode Lock —
HOME LEAVE Operation —
ECONO Mode
{
★
1
Indoor Unit On/Off Switch —
Signal Reception Indicator —
Temperature Display —
Another Room Operation —
Note:
{
: Holding Functions
— : No Functions
★
1 :
★
2 :
This function is mounted only on FTXS20-50D
and FVXS25-50F indoor unit.
Displayed on remote controller of indoor unit.
